DIAL-IN ROTARY LASER - red
DUAL GRADE
DTR80R
The DTR80R features the latest technology red diode offering a bright and sharp line that is perfect for working indoors or outdoors with the receiver.
Dual grade capable which means you can easily adjust the X & Y slopes up to ±5° manually on the laser panel or dial in 0.1% increments via the digital remote from up to 100m.
FEATURES
Horizontal and vertical operations
Manual dual grade
Dial in dual grade via digital 100m remote -
slope up to ±5° (both X and Y axis)
Millimetre detector with digital display and clamp
Speed control and scanning mode
Ni-MH rechargeable battery
Tilt alarm
Specifications
ACCURACY
±1 mm at Ø30m
OPERATING RANGE
Ø800m (with detector)
LEVELLING RANGE
±5 ° / 9%
BATTERY LIFE
20 Hours (continuous operation)
POWER SUPPLY
Ni-MH rechargeable battery pack,
C-Cell battery pack
LINE PATTERN
360° Rotating line & up & down plumb dots
IP RATING
IP65
TRIPOD THREAD
5/8" Thread on side and base
LASER CLASS
IIIR
DETECTOR
Millimetre detector with digital display
and clamp
REMOTE
Digital 100m wireless remote (LCD)
APPLICATIONS
General construction
Plumbing
Bricklaying
Concreting
Landscaping
Site preparation
INCLUDES
Digital 100m wireless remote (LCD)
Digital millimetre detector with clamp
Heavy duty case with EVA foam
Ni-MH rechargeable battery pack
Red laser target
Red laser glasses
C-Cell battery pack
4 C-Cell batteries
Battery power adapter (indoor use)
